Wall light
LED–TAB TOP type 7/2
Wall light LED–TAB TOP type 7/2
Wall light for streets, paths and public spaces
Features
- solid aluminum housing
optionally stainless steel - Powder-coated surface RAL 9006
more colors on request - Orientation: variable 0°, 7° and 11°
- 4 performance variants
from 18 watts (3060 lm) up to 70 watt (10758 lm)
Module with lens technology – format 120 × 120 mm
(Radiation angle symmetrical or asymmetrical) - mit Vorschaltgerät
- Impact-proof, dust-proof, jet-proof IP 65
- Protection class 1 or 2
- with wall mounting
Mark of conformity
Item-No.
Type
luminous flux
illuminant
LED595111S71PA
7/1
5379 lm
LED 35 Watt
LED595111S72PA
7/2
10758 lm
LED 70 Watt
Further wattages and light intensities on request.
Download
DataSheet Wall light TAB TOP Typ 7/1 WL
DataSheet Wall light TAB TOP Typ 7/2 WL
Brochure Wall light LED Tab Top 7
Assembly instructions
Assembly Wall light TAB TOP 7 wall
