Light column FIACCO type 555/140
Light column FIACCO type 555/140
Light column, stainless steel
Design tube
- Ø68 mm stainless steel L304 1.4301 (optionally L316 1.4401)
- Surface glass bead blasted
- Standard length A = 3353 mm
Protective tube
- Protection glass transparent or frosted
- Shockproof, dust-proof, jet-proof IP 65
- Protection class 1 or 2
Reflector disc
- stainless steel V2A / V4A
- Surface glass bead blasted
- Circular plate Ø 600 mm
Ground mounting
- 360° rotatable
- Ground sleeve on request
Marks of conformity
Item-No.
Illuminant
LED501555140000
1960 Lumen LED 14 Watt
500100589
ground sleeve
Available with direct connection (230/220/120/110V) no driver needed.
Further models and illuminants on request.
We also upgrade your existing lights to efficient LED technology.
*We reserve the right of changing specifications in case of technical improvement.
